C-Series Rectifier

Eltek’s Low Power (LP) System is an ideal solution for applications requiring up to 7 amps (redundant) at 48 Vdc with load and battery interfaces. Designed to be either wall or rack mounted, the LP Power System simplifies installation by integrating power conversion, control, output distribution, and optional battery plant in an innovative 5RU system.



Inquiry

Product Introduction

Features & Benefits
  • C0350A rectifier provides 7A at -48Vdc
  • Fan-cooled
  • GR-3108 compliant



Benefits
  • Business communication services:
    High density power with an optional integrated battery box and DC distribution makes the Eltek LP DC Power System the ideal solution for applications powering small multiplexers and FTTx solutions.
  • Reduced installation and maintenance costs:
    Integrated, lightweight, and modular chassis make for easy wall or rack mounting. Fully connectorized feeds reduces field wiring time and errors. Hot swappable rectifiers greatly reduce downtime.
  • Better quality of service:
    Industry leading efficiency, >1,000,000 hrs MTBF, NEBS Level 3 compliance, redundancy, and intelligently designed distribution all result in reliable, trouble-free networks.
  • Flexibility of deployment:
    Battery and power enclosures may be deployed independently. A battery enclosure may be added at any time to provide improved reliability. A power enclosure may be deployed as a stand-alone unit.



Specifications
  1. Input
  2. Current (maximum): 4.6 ADC
  3. Voltage AC (operating range): 90 - 264 VAC
  4. Max Input AC Voltage: 264 VAC
  5. Mains Configuration: 120V/208V
  7. DC Output
  8. Max Power: 392 W
  9. Voltage (adjustable range): 42 - 56 VDC
  10. Current (maximum): 8.4 ADC
  11. Max Voltage: 56 VDC
  13. Battery Distribution
  14. Breaker Positions up to: 1
  15. Breaker Rating up to: 15 A
  17. DC Load Distribution
  18. Breaker Rating up to: 10 A
  19. LVLD: No
  20. Available GMT Fuses: 10
  22. Other
  23. Cooling: Single fan
  24. Efficiency: 90%
  25. Operating Temperature: -40 to 65°C
  26. Storing Temperature: -40 to 70°C
  27. Maximum Battery Trays: 3
  28. Mounting Type: Rack 19”; Rack 23”; Wall
  30. Dimensions
  31. Dimensions (W x H x D): 4.62 x 2.91 x 4.62 inch
  32. Weight: 4 lbs
  34. Certifications
  35. UL: UL 60950-1
  36. Telcordia Approvals: NEBS GR1089-CORE; NEBS GR3108-CORE; NEBS GR63 CORE Zone 4
